AC Capacitor 50+5 uf 50/5 MFD ±5% 370V 440V CBB65 Dual Run Circular Start Capacitor Replacement for AC Unit Motor or Fan Start or Condenser Straight Cool or Heat Pump
Product details
| Management number | 218167620 | Release Date | 2026/05/03 | List Price | $8.40 | Model Number | 218167620 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 【High Performance】This KBT ac capacitor has C Class in operating, 10000 AFC. Low loss and high insulation resistance.Good self-healing performance
- 【Operating Details】Capacity Range: ± 5% (standard deviation). Operating Temperature Range: -40 ° C to+70 ° C/-104 ° F to+158 ° F.Size measures ( 2.16inch / 55mm ) x ( 4.72inch / 120mm )
- 【UL Certified】This capacitor has passed the UL(Certificate No.E309467 )、and TUV certifications. Ex. Grade S2 explosion-proof design, reliable and safety
- 【Easy To Replace】No wiring or adapter changes are required. There are three terminals on the top of the AC capacitor: the compressor motor is marked "Herm," the fan is marked "Fan," and the common line is marked "C." For AC Unit Fan Motor Start, Heat Pump, or Condenser Straight Cool.
- 【Suitable Model】Replacement for 97F9850 , 97F9970 , 97F9970BZ3 , TRCFD505 , RC0120 , 12790 , RC0121, 1094993 , 38514D018 , P2915053R , HC98CA050 , P291-5053RS , 024-25338-000 , 43-25133-25 , P291-5053R , HC98JA051 , 43-23204-15 , 432320415 , 05706036 , D6789043 , B94577400 , B945774-00 , CARG32458 , TT-CAP-50/5/440R , 27L601 , TP-CAP-50/5/440R , HCKS500D050R440Z , B9457-7400. Starting and running ofsingle-phase asynchronous motor at 50Hz/60Hz frequency power
| Brand Name | KBT KEEP BETTER TECH |
|---|---|
| Item Shape | Round |
| Item Weight | 9.79 Ounces |
| Part Number | CBB65S-MFC-50+5-001 |
| Manufacturer | KBT |
| Material Type | Aluminum |
| Mounting Type | Through-Hole Mount |
| Maximum Voltage | 450 Volts |
| Operating Voltage | 120 Volts |
| Included Components | normal |
| Capacitance Tolerance | ±5% |
| Item Dimensions W x H | 2.16"W x 4.72"H |
| Upper Temperature Rating | 158 Degrees Fahrenheit |
| Maximum Storage Temperature | 104 Degrees Fahrenheit |
| Minimum Storage Temperature | 14 Degrees Fahrenheit |
