CHANZON High Power Led Chip 50W Infrared (IR 850nm / Input 1500mA / DC 14V - 16V / 50 Watt) SMD COB Light Emitter Diode Components 50 W Night Vision Bulb Lamp Beads for DIY Lighting/CCTV Cameras
Product details
| Management number | 211326864 | Release Date | 2026/04/04 | List Price | $15.20 | Model Number | 211326864 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specification:Quantity: 1 piece / PackBrand: ChanzonPower: 50 Watt (Max)Emitting Color: Infrared (IR 850nm)Recommended Current: 1500mAForward Voltage: 14-16VLuminous Flux: NoEmitting Angle: 120-140 degreeWith Double Golden Wire (99.99%) and Copper FrameKindly Reminder:Constant current LED drivers are recommended for high power COB LEDs.Working temperature should be less than 60 Degrees Celsius / (140 Fahrenheit) with a Heat Sink System.Please refer to the positive (anode +) and negative (cathode -) sign on Leds.Related Accessories:LED Lens Kit 20-100W 44mm (60 degree): ? Search B06XKV9PWY on Amazon
- 50Watt / Infra Red / 850nm / 45mil chips / 120 - 140 degree Light Emitting Angle Lightbulbs
- Integrated Chanzon High Quality High Brightness Chip on Board / Double Golden Wire / Copper Frame)
- Integrated Chanzon High Quality COB LED Panel, High Brightness Chip on Circuit Board / Double Golden Wire / Copper Frame)
- 50000 Hours Life Span (Working Temperature should be less than 60℃（140F) with a Heat Sink System)
- Total Shipping Weight: 1.27oz / 0.036kg (Pack of 1)
| Shape | Circular |
|---|---|
| Voltage | 18 Volts |
| Wattage | 50 watts |
| Beam Angle | 1.4E+2 Degrees |
| Brand Name | CHANZON |
| Brightness | 500 lumen |
| Light Type | LED |
| Unit Count | 1 Count |
| Light Color | Red |
| Manufacturer | CHANZON |
| Model Number | HM-01116 |
| Power Source | DC |
| Material Type | copper |
| Control Method | Touch |
| Bulb Shape Size | B17 |
| Controller Type | Push Button |
| Number of Items | 1 |
| Package Quantity | 1 |
| Light Source Type | LED |
| Power Consumption | 50 Watts |
| Additional Features | Electrode Type: Copper |
| Indoor Outdoor Usage | Indoor |
| Light Source Wattage | 50 Watts |
| Color Rendering Index | 70 |
| Connectivity Technology | Infrared |
| Specific Uses For Product | Lamp |
| Accepted Voltage Frequency | 100 to 120 Volts and 60 Hertz |
| Light Source Operating Life | 50000 Hours |
