DMX512 to 4CH 0-10V Decoder 0-10V LED Dimmer DMX512 Signal to 0-10V Signal RGB/RGBW Controller 4 Channel Dimmer 5-24V
Product details
| Management number | 210100617 | Release Date | 2026/04/02 | List Price | $12.40 | Model Number | 210100617 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Technical parameters Input voltage: 5-24VDC Input signal: DMX512. Output signal: 0-10V Dimming range: 0-100% Working temperature: -30¡æ~55¡æ Dimension: L115¡ÁW48¡ÁH67mm Summary Compatible with a variety of DMX512 masters. 0-10V LED driver which receives and converts DMX512 signal to 0-10V signal. DMX512 compliant control interface, DMX address can be set easily and shown on the digital numeric display. It can also work as stand-alone RGB/RGBW controller, have 30 kinds dynamic mode,adjustable speed and brightness. It can also work as stand-alone 4 channel dimmer, each channel adjust brightness independently, and save up to 8 groups brightness. Connect with 0-10V input dimming driver, such as 0-10V dimmable power supply,realize fine and smooth dimming.
- Compatible with a variety of DMX512 masters.
- 0-10V LED driver which receives and converts DMX512 signal to 0-10V signal
- DMX512 compliant control interface, DMX address can be set easily and shown on the digital numeric display.
- It can also work as stand-alone RGB/RGBW controller, have 30 kinds dynamic mode,adjustable speed and brightness.
- It can also work as stand-alone 4 channel dimmer, each channel adjust brightness independently, and save up to 8 groups brightness. Connect with 0-10V input dimming driver, such as 0-10V dimmable power supply,realize fine and smooth dimming.
| UPC | 747301915434 |
|---|---|
| Color | Dl |
| Model | DL |
| Wattage | 1000 watts |
| Terminal | Screw |
| Brand Name | Nutbro |
| Unit Count | 1.0 Count |
| Item Weight | 0.33 Pounds |
| Switch Type | Dimmer Switch |
| Circuit Type | 4-way |
| Contact Type | Normally Open |
| Manufacturer | FlyBoy2016 |
| Material Type | Metal |
| Mounting Type | Panel Mount" or "Plate Mount |
| Connector Type | Plug In |
| Control Method | App |
| Current Rating | 1 Milliamps |
| Operation Mode | ON-OFF |
| Item Dimensions | 2.64 x 18.9 x 26.38 inches |
| Contact Material | Metal |
| Operating Voltage | 24 Volts |
| Specification Met | Dmx512 |
| Number of Positions | 4 |
| Connectivity Protocol | DMX512 |
| International Protection Rating | IP54 |
