GHXAMP 2-Way Button Type Sound Source Switching Board Signal Input not Common-Ground Mechanical Switch Type (No Power Needed)

Usage of 2-way audio source switching board:The design of signal inputs that are not in common can avoid noise caused by interference from multiple signal inputs in common. Due to the use of mechanical switch design, there is no directionality, so there can be different ways of use, as followsMethod 1: 2 Select 1 method (Signals can be input from 2 IN terminals and output from OUT1 terminal through switching switches).Method 2: 1 in 2 (Dual Channel signal input from OUT end, OUT1, output from IN1-IN2 end through toggle switch).The input and output of the sound source adopts a 6-hole socket. The input and output hole positions can be customized.Adopting a button type mechanical switch, the signal input is not grounded, no power supply is required, and there is no electromagnetic interference. The sound source input and output adopts a sealed socket.Switch switch board size: 30mm * 25mmsocket interface spacing: 14mm (spacing between all 6 holes)==========Package : YesMaximum Power Per Channel : NO POWEROrigin : Mainland China

• Usage of 2-way audio source switching board:
• The design of signal inputs that are not in common can avoid noise caused by interference from multiple signal inputs in common. Due to the use of mechanical switch design, there is no directionality, so there can be different ways of use, as follows
• Method 1: 2 Select 1 method (Signals can be input from 2 IN terminals and output from OUT1 terminal through switching switches).
• Method 2: 1 in 2 (Dual Channel signal input from OUT end, OUT1, output from IN1-IN2 end through toggle switch).
• The input and output of the sound source adopts a 6-hole socket. The input and output hole positions can be customized.
