l0cas is a Bluetooth controllable, Casambi enabled, two-channel analog 0-l0VDC input dimmer that allows connection to a standard 0-l0VDC analog dimming master controller to a Casambi network. While the Casambi manufactured CBU-A2D is intended to connect to analog controlled fixtures, the l0cas is the “other side”, allowing for standard 0-l0VDC controllers to be utilized with Casambi networks. The l0cas is connected between an l2-24 VDC Class 2 power supply, and a 0-l0VDC master with one or two channels. l0cas can implement up to two Casambi pushbutton devices, making it an ideal partner for tunable white (TW) applications. Multiple l0cas devices can be used in the same network to control different fixtures, channels, or zones since the two channels of control can be mapped using the Casambi mobile application. l0cas can be configured with the Casambi app which can be downloaded. Different Casambi-enabled products can be used from a simple single luminaire direct control to a complete and full-featured light control system where many units automatically form an intelligent mesh network.

• INPUT: Voltage range: 12-24 VDC, Class 2 - No-load input current: 30 mA
• 0-l0VDC Input (A and B): 2-wire analog 0-l0VDC, two channels lmA source current, the input must sink for control. Top and bottom “trim” and hysteresis user programmable.
• RELAY CONTROL OUTPUT: Output voltage: 12-24 VDC, same as input. Max. output current: 100 mA
• RADIO TRANSCEIVER: Operating frequencies: 2.401-2.483 Ghz Maximum output power: typ. +0 dBm, +/-3dBm
• CONNECTORS: Wire range, solid & stranded: 0.5 – 1.5 mm2 14 – 22 AWG Wire strip length: .25” (6 – 7 mm) Tightening force: 0.4 Nm / 2.6 Lb-in
