Panduit BSH14-Q Heat Shrink Butt Splice, 16 - 14, AWG Wire Range, Blue (25-Pack)
Product details
| Management number | 211032216 | Release Date | 2026/04/04 | List Price | $36.00 | Model Number | 211032216 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This Panduit BSH14-Q heat shrink butt splice connector is suitable for repairing or extending stranded copper wires from #16 to #14 AWG (1.5 to 2.5 sq. mm). It has a tin-plated copper body and a blue polyolefin heat shrink sleeve with a hot melt adhesive for protection against moisture. This connector has a continuous operating temperature range of -65 to +230 degrees F (-55 to +110 degrees C), a maximum voltage rating of 600V, and an internal wire stop for ensuring the proper insertion depth of stripped conductors. It is Restriction of Hazardous Substances (RoHS) compliant for hazardous substance regulations and is Underwriters Laboratories (UL) Listed and Canadian Standards Association (CSA) certified for quality assurance. This heat shrink butt splice connector is suitable for use with stranded copper wires from American Wire Gauge (AWG) #16 to #14 (1.5 to 2.5 sq. mm) in a wide range of industrial, automotive, and other electrical applications.SpecificationsConnector typeButt splice, insulated, heat shrinkFor use with stranded copper wire#16 to #14 AWG (1.5 to 2.5 sq. mm)Color codeBlueCompatible with Panduit crimping toolsCT-310Length (before shrinking)1.45" (36.8 mm)Maximum wire insulation diameter0.19" (4.83 mm)Wire strip length5/16"Body materialTin-plated copperInsulation materialPolyolefinInsulation shrink temperature300 degrees F (150 degrees C)Maximum voltage rating600VContinuous operating temperature range-65 to +230 degrees F (-55 to +110 degrees C)Standards metUL Listed, CSA certified, RoHS compliantPanduit manufactures electrical and networking products. The company, founded in 1955, is headquartered in Tinley Park, Il.
- Heat shrink butt splice connector for repairing or extending stranded copper wires from #16 to #14 AWG (1.5 to 2.5 sq. mm)
- Polyolefin heat shrink sleeve with hot melt adhesive for protection against moisture
- Maximum voltage rating of 600V
- Continuous operating temperature range of -65 to +230 degrees F (-55 to +110 degrees C)
- UL Listed and CSA certified for quality assurance, RoHS compliant for hazardous substance regulations
| UPC | 074983818242 |
|---|---|
| Color | Blue |
| Gauge | 16 - 14 AWG |
| Model | BSH14-Q |
| Terminal | Butt Terminal |
| Brand Name | Panduit |
| Unit Count | 1 Count |
| Manufacturer | Panduit |
| Material Type | Copper |
| Connector Type | Crimp |
| Maximum Voltage | 600 Volts |
| Contact Material | Copper |
| Specification Met | CSA |
| Temperature Rating | 230 degree fahrenheit |
| Insulation Material Type | Polyvinyl Chloride |
