Wireless Remote Switch DC 12V 24V 2 Channel 10A Relays 433mhz Wireless Receiver with Wireless Remote Control Relays +2 Metal Remote for Electric Doors, Cars, Lights, Gate Door Receiver Kits (Black-1)

Package Include: 1 x Receiver(with cover) 1 x Transmitter(with battery) 1 x manual 1 x 1 year warranty Technical parameters: 1. Working voltage: 6V-30V 2. Working frequency: 433.92MHZ 3. Quiescent current: 8.5mA 4. Load power: ≤ 100W at 12v, and so on 5. Receiving sensitivity:-105dBM 6. Coding method: learning code 7. Modulation mode: ASK 8. Working temperature:-20°C ~ 80°C 9. Quiescent current: <5 MA Control mode Description Toggle (1 button on / same button off) Latch (1 button on / other button off) Momentary (Press and hold -> On; Release -> Off) Set the different control modes: Setup： Momentary method: Press the receiver learning button ONCE,After the indicator light goes out, press the A button. After the indicator light of the receiver flashes, the A button is paired and the indicator light enters the off state. Press the B button of the remote controller. After the indicator light of the receiver flashes, the B button completes the code matching, the indicator light enters the constant light, and the code matching is completed. Toggle method: Press the receiver learning button TWICE,After the indicator light goes out, press the A button. After the indicator light of the receiver flashes, the A button is paired and the indicator light enters the off state. Press the B button of the remote controller. After the indicator light of the receiver flashes, the B button completes the code matching, the indicator light enters the constant light, and the code matching is completed. Latch method:Press the receiver learning button THREE times,After the indicator light goes out, press the A button. After the indicator light of the receiver flashes, the A button is paired and the indicator light enters the off state. Press the B button of the remote controller. After the indicator light of the receiver flashes, the B button completes the code matching, the indicator light enters the constant light, and the code matching is completed. Momentary+Toggle: Press the receiver learning button FOUR times,After the indicator light goes out, press the A button. After the indicator light of the receiver flashes, the A button is paired and the indicator light enters the off state. Press the B button of the remote controller. After the indicator light of the receiver flashes, the B button completes the code matching, the indicator light enters the constant light, and the code matching is completed. Reset Press the learning button 8 times on the receiver. succeed. Notice: Reset before you want to change the operating mode of one remote control. After reset, all the remote controls cannot work anymore.

• Signal stability and range: RF remote control uses RF technology and stable signal. The signal from the wireless RF switch can be routed to walls, floors and doors, and continuously control the receiver from any position with a reliable distance.The product is a relay output that can control devices with different voltages.
• Wide Work Voltage DC 6V-30V+ 4 working modes: standard is Momentary, We have made transmitter and receiver working together and test it before ship it,when you get it don't need to do anything ,just install it. Working modes of Momentary, Latch, Toggle, and Momentary+Latch
• Signal Stability+ metal remote control ：RF remote control adopts RF technology, stable signal. The signal from the wireless RF switch can be routed to walls, floors and doors, and continuously control the receiver from any position with a reliable distance.Max range is up to 20--50 meters with no obstacle.
• Easy to control+Dry contact signal: You can learn multiple remote controls, and multiple remote can control one receiver. No interference: Using digital coding, the products will not interfere with each other in the same environment where multiple groups of products of the same model are used. The radio receiver is a relay output/potential free, with NO, NC, COM, （Normally open+Normally closed+Common terminal）.
• 1 year warranty: The product has been paired before delivery, you can use it directly, and the product provides a 1-year warranty.
